24" Widescreen Color-Critical Desktop Monitor
MODEL: LCD2490WUXI2-BK
This product has been replaced by P241W-BK
Touting many advanced color performance technologies, the 24” NEC MultiSync LCD2490WUXi2 equips you with all of the features and benefits ideal for high-end graphics applications.
  • Real Time Clock has the ability to set schedules for on/off times 24/7 and can be set to warm up 30 minutes before use for optimum color representation
  • ECO Mode™ function helps save power, reduce heat and extend the life of the display by allowing you to dim the backlight
  • 4-way ergonomic design (height-adjust, pivot, tilt & swivel) enhances your viewing comfort
  • Superior screen performance (1000:1 contrast ratio, 1920 x 1200 native resolution, 300cd/m2 brightness)
  • Supports 12-bit internal programmable lookup tables (LUTs) for calibration
  • AmbiBright™ ambient light sensor automatically adjusts the display's brightness based on lighting conditions
  • ColorComp™ digital uniformity correction reduces screen uniformity errors and compensates for differences in color/grayscale and luminance across the entire screen
  • Auto Luminance control with X-Light™ Pro backlight/sensor design allows for consistent brightness and color

Qty:




Product Specifications

Display



Panel Technology IPS
Viewable Image Size 24"
Aspect Ratio 16:10
Native Resolution 1920 x 1200
Pixel Pitch 0.27mm
Pixels Per Inch 94@ native resolution
Backlight Type CCFL
Brightness (typical) 320cd/m2
Contrast Ratio (typical) 1000:1
Viewing Angle (typical) 178° Vert., 178° Hor. (89U/89D/89L/89R) @ CR>10
ResponseTime (typical) 8ms
Color Gamut
Adobe RGB Coverage/Size 75.2% / 75.7%
NTSC Coverage/Size 72.1% / 72.4%
sRGB Coverage/Size 93.5% / 102.2%

Lookup Table 12-bit
Displayable Colors 16.7 million out of 68.5 billion


Synchronization Range



Horizontal (Analog/Digital) 31.5-93.8/118 kHz
Vertical 50-85 Hz


Input Signal



Video Analog RGB 0.7 Vp-p/75 Ohms
Sync Separate Sync: TTL Level (Positive/Negative)
Composite Sync: TTL Level (Positive/Negative)
Composite Sync on Green: (0.3Vp-p negative 0.7Vp-p positive)


Input Connectors



DVI-D, DVI-I, VGA 15-pin D-sub


Power Consumption (typical)



On 75W
Power Savings Mode 1W


Physical Specifications



Dimensions (WxHxD)
Net (with stand) 21.8 x 17 x12 in. / 554.2 x 432.4 x 306mm
Net (without stand) 21.8 x 14.2 x 4.1in. / 554.2 x 359.8 x 104mm

Weight
Net Weight (with stand) 26 lbs. / 11.8 kg
Net Weight (without stand) 19.2 lbs. / 8.7 kg



VESA Hole Configuration Specifications



100 x 100mm, 200 x 100mm


Environmental Conditions



Operating Temperature 41-95°F / 5-35°C
Operating Humidity 30-80%
Operating Altitude 10,000 ft. / 3048m
Storage Temperature 14-140°F / -10-60°C
Storage Humidity 10-85%
Storage Altitude 40,000 ft. / 12,192m


Environmental Compliance



RoHS Yes


Limited Warranty (parts & labor, including backlight)



4 years


Additional Features



  • ECO Mode
  • Thin frame
  • Tilt
  • Swivel
  • Pivot
  • Height-adjustable stand
  • Quick release stand
  • Carrying handle
  • Rapid Response
  • Ambix3
  • XtraView+
  • OSD user controls
  • NaViSet software
  • Cable management
  • Touch-integratable
  • Vacation switch
  • VESA mount
  • HDCP
  • DDC/CI
  • No Touch Auto Adjust
  • 12-bit LUT
  • Auto brightness (ambient light sensor)
  • X-Light Pro
  • Black Level adjustment
  • AmbiBright
  • ColorComp image uniformity correction
  • Real-time clock
  • CableComp
  • TileMatrix
  • TileComp
  • GammaComp MD QA software
  • SpectraView software-ready


Ships With



  • Power cord
  • 15-pin D-sub cable
  • 15-pin D-sub to DVI-A
  • DVI cable
  • Cable Cover
  • Mounting Screws


Accessories



Optional
  • SpectraViewII Color Calibration Kit (SVII-PRO-KIT)
  • Color calibration sensor (MDSVSENSOR2)
  • SpectraView software (SVIISOFT)
  • Hood (HDPA212426)
  • Multimedia soundbar - black (SOUNDBAR90-BK)
